BSLBATT  |  SKU: BSL-B-LFP48-200PW

BSLBATT – LiFePO4 48V/200Ah Solar Wall Battery | B-LFP48-200PW

$3,528.00 CAD
Shipping calculated at checkout.

The B-LFP48-200PW is a 51.2V 200Ah 10kWh wall-mounted LiFePO4 battery engineered for residential energy storage. It delivers over 6000 cycles at 90 percent DOD with a 10-year design life, supports most 48V inverters, and adopts a high-efficiency DC-coupled architecture.

An intelligent BMS provides comprehensive protection, while parallel connection of up to 32 units allows flexible system expansion, backed by BSLBATT quality and a 10-year warranty.

Warranty

This product is covered by a 10 years limited warranty

Delivery and Shipping

Orders are shipped within 2 business days. If a problem prevents us from shipping your order within this time, we will notify you.

Depending on your delivery location, transit time will vary from 1 day to 5 days

Note for US and Internationnal buyers: the customer is responsible for paying any import costs to the shipping carrier, such as duties, import taxes, or brokerage/disbursement fees which may apply upon delivery.

Technical Specifications User manual
UL 1973 Certificate of Comformity

BSLBATT – LiFePO4 48V/200Ah Solar Wall Battery | B-LFP48-200PW at a glance

  • Technology

    LiFePO4

  • Group Size

    N/A

  • Dimensions (H x W x D)

    33.9 X 20.1 X 5.8 in
    860 X 510 X 147 mm

  • Weight

    209 lbs / 95 kg

  • Voltage

    48V

  • Capacity (Ah)

    200 Ah

  • Capacity (kWh)

    9.728 kWh

BSLBATT – LiFePO4 48V/200Ah Solar Wall Battery | B-LFP48-200PW

Key Specifications

  • Battery voltage: 51.2V
  • Battery Energy: 200Ah
  • Battery capacity: 10kWh
  • Standard charging current: 80A
  • Maximum charging current: 160A
  • Standard discharge current: 200A
  • Maximum discharge current: 210A
  • Cycle life: >6000 cycles @ 90% DOD
  • Warranty: 10 Years
  • Certification: UN38.3, IEC62619, UL1973

Best Applications for a 10kWh LiFePO4 Home Battery

The B-LFP48-200PW is designed for homeowners and solar professionals who need a reliable, cost-effective energy storage solution. Its compact wall-mounted form factor saves valuable floor space while delivering the same 10.24 kWh capacity as larger rack-mounted systems.

This battery is an ideal choice for residential solar self-consumption, allowing you to store excess solar energy during the day and use it at night to reduce electricity bills. It also serves as a dependable backup power source during grid outages, keeping essential loads such as lighting, refrigeration, and communication equipment running for hours.

For households on time-of-use (TOU) electricity tariffs, the B-LFP48-200PW enables smart load shifting. Charge the battery during off-peak hours when rates are low, then discharge during peak hours to avoid premium pricing. Over the battery's 15-year design life, this strategy can offset a significant portion of your total energy costs.

Leading BMS

Multiple Protection Functions

The built-in battery management system (BMS) provides comprehensive protection for every charge and discharge cycle.

Safety features include overcharge protection, deep discharge protection, overcurrent protection, short circuit protection, over-temperature shutdown, and real-time cell-level voltage balancing.

The BMS communicates with your inverter via CAN, RS485, or RS232 protocols, ensuring seamless system integration and remote monitoring capability.

Optional Wi-Fi and Bluetooth modules allow homeowners to check battery status from a smartphone app.

How to connect your BSLBATT 48V Battery to TBB All-In-One Solar Inverter
