RV Kit E - 600Ah battery with 2 X 395W solar panel

2 X 395W Solar Panel Kit

• 2 X Canadian Solar – Hiku6 – 395W Monocrystalline Solar Panel
• 1 X Electric Solar Boat Cable #10 - 2 conductors - 15ft
• 1 X Solar Panel Cable Entry Gland (White)
• 1 X MidNite Solar Baby Box enclosure
• 1 X MidNite Solar, 20A, 300 VDC, DIN rail mount breaker, 13mm wide
• 2 X Universal “Z” bracket roof mounting system for solar panel

150V/60A Charge Controller Kit

• 1 X Victron Energy SmartSolar MPPT 150/60-Tr Solar Charge Controller
• 2 X MEGA-fuse 80A 80V fuse
• 1 X 36'' #4 Solar charge controller cables (pair) - 3/8" lug on one end

2 X 300Ah LiFePO4 Battery Kit

• 2 X Victron Energy – 12V/300Ah Lithium LifePO4 NG Battery
• 1 X 36'' #2/0 Black jumper battery interconnection cable with lugs
• 1 X 36'' #2/0 Red jumper battery interconnection cable with lugs
• 1 X 12'' #2/0 Black jumper battery interconnection cable with lugs
• 1 X 12'' #2/0 Red jumper battery interconnection cable with lugs
• 1 X Victron Energy VE.Bus BMS V2
• 1 X Victron Energy RJ45 UTP Cable 1.8m
• 1 X 10' Black #18 Electrical cable for inside distribution use / 1 conductor
• 1 X Victron Energy Fuse holder 6-way for MEGA-fuse
• 1 X Victron Energy – Busbar – 4 Studs – 70V/150A
• 1 X Victron Energy SmartShunt 500A
• 1 X Victron Energy Battery Switch ON/OFF 275A
• 1 X 12'' #2/0 Black jumper battery interconnection cable with lugs
• 1 X 12'' #2/0 Red jumper battery interconnection cable with lugs
• 1 X Victron Energy Orion-Tr 12/12-9A (110W) Isolated DC-DC Converter
• 1 X 12-way fuse holder for ATO fuse
• 2 X Victron Energy BatteryProtect 12/24V-100A
• 2 X AWG 16-14 cable lugs - #8 ring
• 1 X 10'' Black #10 electrical cable for inside distribution use / 1 conductor
• 1 X 10'' Red #10 electrical cable for inside distribution use / 1 conductor
• 2 X AWG 12-10 cable lugs - #8 ring
• 2 X AWG 12-10 cable lugs - 1/4" ring
• 4 X AWG 12-10 cable lugs - 3/8" ring
• 1 X 12'' #4 Black jumper battery interconnection cable with lugs

12/12-50 DC-DC Charger Kit

• 1 X Victron Energy Energy Orion XS 12/12-50A DC-DC battery charger
• 1 X 36'' #6 Solar charge controller cables (pair) - 3/8" lug on one end
• 1 X 25'' Red #6 battery interconnection cable
• 1 X 5'' Black #6 battery interconnection cable
• 5 X AWG 6 cable lugs - 3/8'' ring
• 4 X MEGA-fuse 60A 80V fuse
• 1 X Victron Energy Fuse Holder for MEGA-fuse

Inverter/Charger 12/3000/120-50 120V Kit

• 1 X Victron Energy MultiPlus-II 12/3000/120-50 120V (UL certified) Inverter/Charger
• 1 X 24'' #2/0 Black jumper battery interconnection cable with lugs
• 1 X 24'' 2/0 Red jumper battery interconnection cable with lugs
• 2 X MEGA-fuse 400A 80V fuse

Wire Ducts

• 2 X Plastic Wire Duct - 36 inches.
