The GX IO-Extender 150 enhances the input and output (I/O) capabilities of a GX device, enabling seamless integration with additional sensors, controls, and external devices.
It connects via USB, which also serves as its power source, providing a simple and efficient expansion solution. The device can be controlled using Node-RED on the GX device as well as the Switch pane in the user interface.
Victron Energy GX IO-Extender 150 | BPP900800150
is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Warranty
This product is covered by a 5 year limited warranty
Delivery and Shipping
Orders are shipped within 2 business days. If a problem prevents us from shipping your order within this time, we will notify you.
Depending on your delivery location, transit time will vary from 1 day to 5 days
Note for US and Internationnal buyers: the customer is responsible for paying any import costs to the shipping carrier, such as duties, import taxes, or brokerage/disbursement fees which may apply upon delivery.
The GX IO-Extender 150 enhances the input and output (I/O) capabilities of a GX device, enabling seamless integration with additional sensors, controls, and external devices. It connects via USB, which also serves as its power source, providing a simple and efficient expansion solution. The device can be controlled using Node-RED on the GX device as well as the Switch pane in the user interface.
Features
8 digital I/Os, configurable as 8 inputs, 8 outputs or 4 inputs + 4 outputs
PWM output for precise control applications
Two latching relays for low-power switching
A solid switch for controlling DC loads that can be resistive, capacitive or inductive (such as the coil of a high-power contactor)
Pluggable spring terminals for fast and secure connections
Configurable via Node-RED for easy automation and custom logic
Technical Note:
The digital outputs can source 4mA max. When driving 4mA, the voltage drop across the internal series resistor (560 Ω) is 2.24V, which leaves only 2.76V @ 4mA for the output signal. Therefore, a driver like a transistor or FET is required to switch a relay with a digital output.
GX IO Extender 150 giving you more switching options
The GX IO-Extender 150 enhances the input and output (I/O) capabilities of a GX device, enabling seamless integration with additional sensors, controls, and external devices.
It connects via USB, which also serves as its power source, providing a simple and efficient expansion solution. The device can be controlled using Node-RED on the GX device as well as the Switch pane in the user interface.
