Midnite Solar  |  SKU: BOS-DISJ-MNEDC20

MidNite Solar, 20A, 150 VDC / 120 VAC breaker | MNEDC20

$41.34 CAD
Shipping calculated at checkout.

20 Amp 150 VDC/120 VAC breaker.

All MidNite circuit breakers can be used at 100% rated current when mounted in a MidNite enclosure.

Warranty

This product is covered by a 5 years limited warranty

Delivery and Shipping

Orders are shipped within 2 business days. If a problem prevents us from shipping your order within this time, we will notify you.

Depending on your delivery location, transit time will vary from 1 day to 5 days

Note for US and Internationnal buyers: the customer is responsible for paying any import costs to the shipping carrier, such as duties, import taxes, or brokerage/disbursement fees which may apply upon delivery.

Technical Specifications User manual

MidNite Solar, 20A, 150 VDC / 120 VAC breaker | MNEDC20

MidNite's breakers are rated to break the full rated load at the rated voltage repeatedly, with NO DAMAGE. Always use a properly sized breaker for disconnecting.

All MidNite circuit breakers can be used at 100% rated current when mounted in a MidNite enclosure.

  • NON POLARIZED
  • Listed for 120vac and 150vdc
  • Width 0.75 inch
  • 1/4 inch studs
  • Breaker Torque Value: 30 In-Lbs (3.4NM)
  • Environmental Rating - Type 1 (Indoor)
  • Listed for US & Canada when used in appropriate breaker box
  • Includes two 6-32 x 0.195” Pan Head Phillips mounting screws
