Victron Energy  |  SKU: CONV-DCDC-VIC-ORION-TR-48V/24V-12A-ISO  |  Barcode: 8719076035299

Victron Energy Orion-Tr 48/24-12A (280W) Isolated DC-DC Converter | ORI482428110

$159.92 CAD
Shipping calculated at checkout.

The Victron Energy Orion-Tr 48/24-12A (280W) is an isolated DC-DC converter designed to provide stable and reliable 24V DC power, even in demanding conditions.

With a 12A capacity and a 280W nominal power rating, this converter is ideal for electrical systems in vehicles, boats, and off-grid installations.

Warranty

This product is covered by a 5 years limited warranty

Delivery and Shipping

Orders are shipped within 2 business days. If a problem prevents us from shipping your order within this time, we will notify you.

Depending on your delivery location, transit time will vary from 1 day to 5 days

Note for US and Internationnal buyers: the customer is responsible for paying any import costs to the shipping carrier, such as duties, import taxes, or brokerage/disbursement fees which may apply upon delivery.

Technical Specifications User manual

Victron Energy Orion-Tr 48/24-12A (280W) Isolated DC-DC Converter | ORI482428110

Remote on/off terminal

The remote on/off terminal eliminates the need for a high current switch in the input wiring. The remote on/off can be operated with a low power switch or by for example the engine run/stop switch (see manual).

All models are short circuit proof and can be paralleled to increase output current

An unlimited number of units can be connected in parallel.

High temperature protected

The output current will reduce at high ambient temperature.

IP43 protection

When installed with the screw terminals oriented downwards.

Screw terminals

No special tools needed for installation.

Input fuse (not replaceable)

On 12 V and 24 V input models only.

Adjustable output voltage

Not intended for battery charging.

Please consider using an Orion-Tr Smart for battery charging.
